Aggregate Crusher and Processing

Aggregate Crusher and Processing

Production line is introduced: The raw stones like granite, basalt, marble, limestone, cobble stone etc crushed by jaw crusher and impact crusher;the crushed stone will be sieved into different grade by vibrating screen, , aggregate washing machine will be needed to clear away the dust and small particles.

Machinery Recommended: Jaw Crusher + Cs Series Cone Crusher + Cone Crusher + Ball Mill + Flotation Machine + Magnetic Separator + Sand Screening Machine +

Email: sales@shibochina.com

Aggregate Manufacturing typically starts by blasting rock masses and is followed by a series of crushing stages. Crushing operations can accommodate some adjustment to match the demand for each gradation. Aggregate is a broad category of coarse particulate material used in construction, including sand, gravel, crushed stone, slag, recycled concrete and geosynthetic aggregates. Aggregates are the most mined material in the world.

AGGREGATE CRUSHER & PROCESSING

Henan Shibo Mechanical Engineering Co.,ltd is a premier supplier of crushing and screening equipment, and related auxiliary equipment in China. We provide complete crushers and screen machines for producing all types of aggregate. The input capacity of One unit of aggregate production line up to 800-1000 TPH, the input size is 0-15mm.

Aggregate production line produce construction aggregates widely used for making concrete production. The aggregate process consists by progressive stages of crushing, screening, and washing.

The aggregate production flow:

1.The blasted raw stones was hauled to the a stockpile by heavy duty truck;

2.The raw stones like granite, basalt, marble, limestone, cobble stone etc. will be fed into jaw crusher as primary crushing machine;

3.The crushed stones will be transferred to impact crusher for further processing;

4.According to the clients application, the crushed stone will be sieved into different grade by vibrating screen, or be transferred to cone crusher for fineness crushing;

5.After screening process, aggregate washing machine will be needed to clear away the dust and small particles.

Aggregates are a component of composite materials such as concrete and asphalt concrete; the aggregate serves as reinforcement to add strength to the overall composite material.Complete stationary, portable, mobile aggregate crushing machine are available. Our aggregate crusher equipment with ISO and CE certificates have been sold to countries all around the world.

Aggregate production line manufactured by SHIBO aims for producing crushed stone aggregate. Crushed stone aggregate is produced from many natural deposits including: limestone, granite, trap rock and other durable mineral resources.

Technical Parameters

Capacity(TPH) < 50 50-80 80-120 120-180 180-250 250-320 320-420
Vibrating Feeder GZD3000X850 GZD3000X850 GZD3800X960 GZD3800X960 GZD4200X1100 GZD4900X1100 GZD6000X1300
Jaw Crusher PE400*600 PE500*750 PE600*900 PE750*1060 PE900*1060 PE900*1200 PE1000*1200
Cone Crusher PYB900 CS75 PYB1200 CS160 PYB1750 CS160 ×2 PYB1750 ×2
Vibrating Screen YZS1237 YZS1548 YZS1548 YZS1848 YZS2160 YZS1848 ×2 YZS2160 ×2
Belt Conveyor B650 B650 B800 B1000 B1000 B1200 B1200
Feeding Size < 320mm < 420mm < 500mm < 630mm < 685mm < 750mm < 850mm

Advantages of Production Line

Strict quality control system and decades of years production technology make stone crusher plant better performance, higher crushing efficiency and longer service life.
