Position: Home > Products > Beneficiation Equipment > Spiral Classifier
Spiral Classifier Email us at: sales@shibochina.com

Spiral Classifier

small, medium and large models are in stock available

Feeding Size: ≤10mm Processing Capacity: 20-23300t/d

Hot model

FG-12 FG-15 2FC-15 FC-20

Spiral sand washing machine is divided into double helix and single spiral. Can be cleaned and separated from the gravel in the soil and debris, its novel sealing structure, adjustable overflow weir plate, reliable transmission device to ensure the effect of cleaning dehydration. Widely used in highway, hydropower, construction and other industries of washing, grading, impurity, and fine-grained and coarse-grained material washing and other operations, the construction and road construction with gravel is particularly appropriate.

Spiral Classifier

The spiral sand and gravel washing machine structure is reasonable, easy maintenance, handling capacity, power consumption is small, high degree of washing. The new sealed structure, fully enclosed oil bath drive, adjustable overflow weir plate, to ensure that the series of products efficient, durable, cleaning, dehydration effect, fine grain products to maintain stability and so on.Material from the top of the machine into the high-speed rotation of the impeller, under the action of high-speed centrifugal force, and another part of the umbrella-shaped flow in the impeller around the material to produce high-speed impact and crushing, the material after the impact, Between the chassis to form the eddy current several times the impact of each other, friction and smash, from the lower part of the direct discharge, the formation of closed loop many times, by the screening equipment control to achieve the desired finished product size.

Model Spiral diameter(mm) Trough length(mm) Spiral rotation speed(r/min) Processing capacity(t/h) Motor power(kw) Dimensions(L×W×H)(mm) Total weight(t)
Sand return Overflow For driving For lifting Length Width Height
FG-3 300 3000 12-30 80-150 20 1.1 ---- 3850 490 1140 0.7
FG-5 500 4500 8-12.5 135-210 32 1.1 ---- 5430 680 1480 1.9
FG-7 750 5500 6-10 340-570 65 3 ---- 6720 980 1820 3.1
FG-10 1000 6500 5-8 675-1080 110 5.5 ---- 7590 1240 2380 4.9
FC-10 8400 675-1080 85 7.5 ---- 9600 1240 2680 6.2
FG-12 1200 6500 4-6 1170-1870 155 7.5 2.2 8180 1570 3110 8.5
FC-12 8400 1170-1870 120 7.5 2.2 10370 1540 3920 11
2FG-12 6500 2340-3740 310 15 4.4 8230 2790 3110 15.8
2FC-12 8400 2340-3740 240 15 4.4 10370 2790 3920 17.6
FG-15 1500 8300 4-6 1830-2740 235 7.5 2.2 10410 1880 4080 12.5
FC-15 10500 1830-2740 185 7.5 2.2 12670 1820 4890 16.8
2FG-15 8300 2280-5480 470 15 4.4 10410 3390 4080 22.1
2FC-15 10500 2280-5480 370 15 4.4 12670 3370 4890 30.7
FG-20 2000 8400 3.6-5.5 3290-5940 400 11-15 3 10790 2530 4490 20.5
FC-20 12900 3210-5940 320 11-15 3 15610 2530 5340 28.5
2FG-20 8400 7780-11880 800 22-30 6 11000 4600 4490 35.5
2FC-20 12900 7780-11880 640 22-30 6 15760 4600 5640 48.7
FG-24 2400 9130 3.67 6800 580 15 3 11650 2910 4970 26.8
FC-24 14130 6800 490 18.5 4 16580 2930 7190 41
2FG-24 9130 13600 1160 30 6 12710 5430 5690 45.8
2FC-24 14130 13700 910 37 8 17710 5430 8000 67.9
2FG-30 3000 12500 3.2 23300 1785 40 8 16020 6640 6350 73
2FC-30 14300 23300 1410 ---- ---- 17091 ---- 8680 84.8
